1.3MP SWIR camera with IMX990 - Goldeye G-130

Product focus: Goldeye VSWIR camera with IMX990 InGaAs sensor
https://axiomoptics.com/low-light-cam...

Discover 4 new Goldeye models with the SenSWIR-InGaAs sensors by Sony (IMX990 and IMX991).

1.3MP resolution and VGA resolution with
5µm pitch (smallest pixel pitch in the industry for an InGaAs sensor)
VIS-SWIR sensitivity with high QE from 400 to 1700nm unlocks many applications
Thermoelectric cooling TEC1 for optimal image quality
GigE Vision and CameraLink interfaces

Main features:
Integrated correction data sets, compensation of sensor inhomogeneity and underlying structures (non-uniformity correction – NUC)
Defect pixel correction
Background correction
Automated and manual sensor temperature management via TEC features
Temperature status indicator
Automatic exposure time control
Gain (analog)
I/O configuration and trigger control
Stream hold (deferred image output)
Storable user sets
Firmware update in the field
Region of interest (ROI) control, look-up table (LUT) support, as well as various auto features

Perfectly connected – thanks to powerful software

Have you heard of Vimba, our future-proof and platform independent SDK (software development kit)? Thanks to our in-house software you can easily integrate Goldeye cameras with GigE Vision interface into any system and manage them centrally. Vimba runs on Windows, Linux, and Linux for ARM. With Vimba, you can acquire images and control your Allied Vision camera instantly, program complex vision applications or connect to third-party libraries.

Improvements with SenSWIR sensor technology by Sony

Visible spectral range extension (400nm – 1700nm)

Sony SenSWIR InGaAs sensors are designed with a very thin Indium Phosphide (InP) layer enabling visible light to pass through to the sensitive InGaAs layer. There are already InGaAs sensors available on the market with visible light extension, but Sony is the first manufacturer who managed to keep the quantum efficiency over the full spectral range at a relative high level ( over 50%). In some applications (e.g. spectral imaging, surveillance) this can help to reduce system costs as only a single camera needs to be used.

Higher inspection precision (5µm pixel pitch)
By using Copper-to-Copper connections between the indium-gallium-arsenide (InGaAs) photodiode layer and the silicon readout circuit layer instead of Indium bumps, much smaller pixel sizes of only 5µm² can be realized. This enables imaging with high spatial resolution to reveal smaller object details.

High image homogeneity
Sony SenSWIR sensors are the first sensors we have integrated into the Goldeye camera series with digital outputs. Previous analog sensors require external ADCs resulting in the typical visible vertical striped that are corrected by our NUC. ​​​​​​
In addition, the high image homogeneity of Sony SenSWIR sensors is supported by the Copper-to-Copper connections, that Sony is using in their stacked design, to connect the InGaAs layer with the Silicon Readout IC. They ensure a much more reliable and uniform connection between the two layers vs. existing solutions using Indium bumps.
