L-39 Albatros
Item code: BH183.
SPECIFICATION:
Wingspan: 1,720 mm (67.7 in).
Length: 2,163 mm (85 in).
Weight: 9.6 – 10.5 kg (21 - 23 lbs).
Wing area: 60.7 dm2.
Wing loading: 158 g/dm2.
Wing type: Naca Airfoil.
Servo mount: 37mm x 16mm.
Gear type: Electric Retract Gear with oleo struts (included) and controller box (included).
Parts listing required (not included):
Radio: 8 channels minimum.
Servo: 8 (HV high torque servos) , size: (35 x 15)mm.
Engine: Turbine Jet Engine with thrust 8kg (not included).
Recommended Battery set up (not included):
Battery receiver: 2S- 7.4V 2,200mAh - 3,200mAh.
ALL BALSA - PLY WOOD CONSTRUCTION.
COVERED IN A HEAT-SHRINK FILM WITH PRINTED
