HOW TO; LACROIX Boards Tutorial (Prototipo - DSS50+, DSS60)
Автор: Lacroix Adventures
Загружено: 2018-11-29
Просмотров: 12960
Tutorial for DSS60/DSS50+ available here; https://www.lacroixboards.com/shop
WHAT TO DO WHEN YOU RECEIVE THE BOARD;
1) charge fully right out of the box and always charge fully in general as well (to balance cells).
2) pump tires to 40-50 psi. 50psi gives more range but feels harsher.
3) make sure the screws under each Shockblock is screwed so that the Shockblock is ever so slightly lifted from the truck.
4) wear a helmet, pads, gloves, ride safe and don't be a jerk ;)
WHAT IS COVERED IN THIS TUTORIAL;
0:44; no bearing spacers (MBS Rockstar2 hubs designed to work without spacers, as per MBS).
1:40; top truck info
1:50; enclosure screws and torque setting
2:59; appropriate belt tension (must feel like medium rare steak or... 4 day old tofu (?))
4:11; top truck info
6:20; rear wheels and spacers
8:25; changing motor pulley and belt alignment
9:31; orange Shockblocks in front? explanations.
10:11; motor mounts.
10:30; how to reduce rear wheel wobble.
12:52; rear wheel removal and reinsertion.
13:59; belt slack can occur.
14:12; Shockblock adjustment.
TOOLS YOU'LL NEED TO SERVICE THE BOARD;
Hex;
2mm (motor pulley grub screws), 2.5mm (motor screws), 3mm (truck screws, motor mount grub screw, wheel hubs), and 4mm (Shockblock screws and kingpin).
Socket;
5/8'' (axle nut) and 10mm (kingpin nut).
Drivers;
Philips #2 (motor mount screws).
TORQUE SETTINGS;
enclosure screws (M3*10 countersunk Philips) = Philips #2 - 0.80Nm
motor screws (M4*10 button head) = hex 2.5mm - 2Nm
Wheel hub screws (M4*55)= hex 3mm - 0.55Nm
Motor pulley grub screws (M4*6 grub screw) = hex 2mm - 1.8Nm
Truck kingpin = 10mm socket - 4.6Nm to 5Nm
Tool we use;
Wiha torque Vario-S - https://www.wihatools.com/torque-cont...
Wera torque ratchet - https://www.amazon.com/Wera-050753930...
BONUS INFO;
Rear wheel spacers (what those little round stickers refer to inside the wheel pulley)
pink = 0.5''
green = 31/64''
yellow = 7/16''
orange = 13/32''
orange and yellow (nov 2018 onwards) = 9/16''
