Example 14 on Projection of Plane Surfaces
Автор: Dr Vijetha Vardhan R N - Online Learning Sessions
Загружено: 2020-03-11
Просмотров: 32822
Описание:
A rectangular lamina of 35 mm X 20 mm rests on HP on one of its shorter edges. The lamina is rotated about the edge on which it rests till it appears as a square in the top view. The edge on which the lamina rests is inclined 30 degrees to VP. Draw its projections and find its inclination to HP.
