How to Crimp RJ45 Cat6 Ethernet Cable | Color Coding & Crimping Techniques using a LAN Tester

Welcome to World Class Skill Centre, an initiative by Sun Foundation dedicated to providing essential skills to the youth under the leadership of Padma Shri Mr. ‪@VikramSahney‬ a respected Member of Parliament.
Sun Foundation is Accredited and Affiliated By NSDC

In this tutorial, you'll learn everything you need to know about making and connecting Ethernet cables, specifically focusing on CAT6 cables and RJ45 connectors. We guide you step-by-step through the process of creating a reliable Ethernet cable, from crimping to testing.

You'll discover how to use a crimping tool effectively, whether you're working with a standard crimping tool or a new pass-through connector tool. We'll cover the essentials of Internet wire crimping, straight cable color coding, and how to properly crimp RJ45 connectors onto CAT6 cables.

Key topics include:

How to make Ethernet cables with CAT6 cables and RJ45 connectors
Step-by-step crimping of RJ45 connectors onto CAT6 cables
Using crimping tools, including new pass-through connectors
Color coding for straight cables and proper wire organization
How to punch down LAN cables and connect them to a network
Testing your connections with a LAN tester for optimal performance
