How to Replace AlcoMate AL6000 Prestige Sensor Modules

The AlcoMate Prestige offers user-replaceable sensor modules so that every time you swap out a module, you can restore "Day 1" accuracy and immediately get back to testing. The Prestige is DOT approved for law-enforcement grade accuracy and US Coast Guard Approved to satisfy the requirements of all marine vessels in US waters to have a breathalyzer-on-board.

How-to Tips:

IMPORTANT: Before inserting the new sensor module, you should leave your device powered off, with the old sensor module and batteries removed for at least 5 minutes.

1. Prepare your AlcoMate Prestige.
2. Use a flat, sharp tool to carefully open the top cover, if available.
3. Lift the breath tube to access the sensor module.
4. Remove the breath tube. It should remove easily.
5. Carefully raise the sensor module from the body. Do NOT detach the cable from the body.
6. Remove the cable from the slot underneath the sensor module.
7. Prepare a new pre-calibrated sensor module.
8. nsert the cable into the new sensor. Make sure the blue strip is toward the sensor.
9. Replace the sensor module into its original position.
10. Re-attach the breath tube directly on to the sensor. Make sure the front opening is aligned.
11. Re-attach the cover on to the top of the body. It should snap in fairly easily.

For more technical support for sensor module replacement, please visit us at https://alcomate.net/pages/help-with-....

If you have any questions, please feel free to contact us at support@alcomate.net.
