Switchboard With MCB and connections Diagram. (Part 2)
Автор: Edutainment Youtube
Загружено: 2019-07-06
Просмотров: 37787
Mounting MCB, Switches , socket, etc. on modular switchboard and their connections is shown in this video. It's a part 2.
you can purchase all parts in your nearest electrical store.
MCB 100 to 150 rupees (depends on brand)
Switch 15 to 20 rs for one.
socket 20 rs approx.
indicating lamp 15 approx.
fan regulator 120 to 180 approx.
Price depends on Brand.
Link for circuit diagram :-
https://www.camscanner.com/share/show...
link for series test lamp connection :-
• How to make a Series Test lamp board with ...
link for switchboard connections:-
• Switchboard Switches fitting and connectio...
#Switchboard and Connections
#Connection of MCB, 4 switches, 2 socket, fan regulator, indication lamp
