Cameo - Remove Numbering From Use Case

If the Use Case profile is loaded, it will default to adding numbering onto use cases and actors. This numbering is sometimes undesired. This video explains how to remove the numbers from the diagram and from the containment tree.

This example will provide information regarding Digital Engineering (DE), Model Based Systems Engineering (MBSE), and Systems Modeling Language (SysML).

Video compatible with the following versions of SysML Tools
-Cameo Systems Modeler 19.0
-Cameo Systems Modeler 2021x
-Cameo Systems Modeler 2022x
-Cameo Enterprise Architecture 19.0
-Cameo Enterprise Architecture 2021x (used in this demo)
-Cameo Enterprise Architecture 2022x
-MagicDraw 19.0
-MagicDraw 2021x
-MagicDraw 2022x

Video relevant or similar to the following Tools
-IBM Rational Rhapsody
-Oracle Sparx Systems Enterprise Architect
-Genesys by Vitech
-Microsoft Vizio
