SolidWorks Tutorial: Shoulder Bolt
Автор: Krawchuk Industries LLC
Загружено: 2022-01-26
Просмотров: 1766
In this tutorial, we’re going to model a Shoulder Bolt in Solidworks. Shoulder Bolts are machine screws that have an unthreaded shoulder between the head and the threads. They are used for securing rotating components, such as pulleys wheels and gears.
We’ll start be doing a simple revolve to create our basic profile and then add some physical threads and the Hex cut for the head.
Apologies for the cat in the background. He took it upon himself to let me know he was hungry when I was recording the video.
If you enjoyed it, please hit the like button, and check out the other great videos on the channel.
