[23] Flipper Zero - 7 segment display via GPIO
Автор: Derek Jamison
Загружено: 2023-02-20
Просмотров: 1438
Описание:
In this video, we look at a 7-segment display that is common cathode. We figure out the pins, connect 220 ohm resistors & then use the Flipper Zero to light up different segments.
NOTE: If it had been common cathode; we could have connected the common wire to 3.3V pin and then the outputs would light up when we set them to 0 (GND) value instead of 1 (3.3v) as in this video.
For parts list see my GitHub...
https://github.com/jamisonderek/flipp...
