Troubleshooting TIP-ON BLUMOTION for MOVENTO
Автор: Blum USA
Загружено: 2023-03-02
Просмотров: 74705
In this video, we’ll troubleshoot some common issues that could cause your TIP-ON BLUMOTION for MOVENTO drawer slides to not work properly.
If the drawer won’t open, check for bumpers that could prevent the push-to-open mechanism from activating. If the drawer still won’t open, make sure you have the proper front gap set. Our front gap template makes this a breeze.
If the drawer won’t open when you push the left or right side of the drawer front, make sure you have a synchronization rod connecting the left and right unit together, so they activate and operate at the same time.
If the drawer doesn’t open as far as it should, make sure you have the correct TIP-ON BLUMOTION unit for your application’s weight.
If the drawer makes a loud click when opening, check the adjustments on the MOVENTO runners, make sure the runners are level inside the cabinet, and make sure the drawer box and cabinet are square.
0:00 Intro
0:12 Remove Bumpers
0:34 Set Front Gap
1:51 Ensure Synchronization Rod is Installed
2:50 Ensure you have the correct TIP-ON BLUMOTION Unit
3:13 Check Adjustments on Drawer Runners
3:49 Ensure Drawer Runners are Level
4:08 Ensure Drawer Box and Cabinet are Square
4:30 Outro
For more Blum MOVENTO videos, check out this playlist:
• MOVENTO
