Creating front panels in EasyEDA
Автор: My Modular Journey
Загружено: 2023-06-02
Просмотров: 3232
I've recently had a few conversations on IG about front panels for my diy eurorack modules. Since a lot of the questions are always about the same topics, I decided to make a little video series about my approach.
This is the first video in that series.
There are many different methods, but I personally use EasyEDA. Which is a free browser based program provided by the company behind JLCPCB.
https://easyeda.com/
There are much more versatile and proffesional applications available. But this is by far the most intuitive way of working.
Doepfer A100 description is the design standard for the eurorack platform.
https://doepfer.de/a100_man/a100m_e.htm
For more of my (mainly modular) content, check out my Instagram:
https://instagram.com/my_modular_jour...
#synthdiy #modular #synthesizer #diy #electronics #eurorack #pcbdesign #easyeda
