Tektronix 465 Oscilloscope Testing
Автор: mister_rf
Загружено: 2013-10-06
Просмотров: 35257
The 465 is a legendary product from Tektronix. Tektronix is said to be the company who invented the oscilloscope (in 1946, with model 511).
The 465 came to the market in the early 1970-ties. It was a general-purpose analogue scope with a large bandwidth of 100Mhz and two time bases for a price at that time of ~3500$. Tektronix sold the 465 very well and it is also said to be the most frequent scope in the world.
This model 465: The original one, 100MHz bandwidth. Implemented mostly using transistors, only a few ICs are used in the design. Because the 465 uses only very few integrated circuits, it can be repaired relatively easy.
•100 MHz Bandwidth, Dual Channel
•Vertical Sensitivity - 5 mV/div. to 5 V/div.
•Vertical Modes - Ch. 1, Ch. 2, Add, Alt., Chop, Ch. 2 Invert
•Full-Range Calibrated Delayed Time Base with Precision Delay Time Control
•Horizontal Sweep Speeds: .5 s/div. to .05 ms/div. (With x10 Mag. - 5 ns/div.)
•Horizontal Modes - A, MIX, A INTEN, B
