Penguin Pallet Stretch Wrapping Machine - Model: INNOVA
Автор: Penguin Engineers
Загружено: 2025-09-11
Просмотров: 40
With the knowledge & expertise of Pallet Stretch Wrapping Machine manufacturing for nearly 3 decades, Penguin Engineers have come out with a newly designed Pallet SWM – Model: Innova. The new model have added special features as like: AC Motor, AC Drives, Foldable Mast with Control panel assembly, built-in PLC for indicating parameters & stoppages, provision for easily shifting the machine using fork-lift, Special unique Stretch Unit enabling easy-threading of stretch film & stepless Stretch % setting. All moving chains & gears are completely covered to give total protection to the operator, suitable for Pallets of max. Size: 1.2 x 1.2 x 2.6 M & 2.0 Tons Pallet load.
Stretch Wrapping Machine – Model: Innova consists of 2600 mm height Mast with elevator for the stretch unit, duly hinged & foldable on to the 1650 mm diameter Turn Table with a capacity to hold & stretch wrap 2000 kgs of Pallet load, Powered Pre-Stretch Unit, powered by motor for stretching the LLDPE stretch film up to 300% using PLC, adjustable Ramp for easy & convenient loading and unloading of pallets with hand pallet truck, driven by 3 Nos., A.C. Motors, (T.E.F.C. type) with A.C. drives for infinite variation of speeds, life-time lubricated Gear Boxes, suitable Control panel for automatic cycle of operation, suitable built-in PLC, stop motions
