Jensen #20 GG steam plant
the GG stands for Generator / Governor
sits on an Oak plinth 14.5" X 17.5" , has a all copper functioning water tower that stands 9.5" X 3" OD flowing water through 1/4" brass tubing to a PMR water feed pump & continuous through a check valve & then into the boiler, the boiler has a pressure gauge in front. Steam then flows through the functioning governor & into the #20 steam engine. the engine is powering a specially modified generator that has roller ball bearings in each of the bearing towers, the original Jensen axle was replaced with a 4" axle & 2 4 tiered pulleys are on either end to act as a transmission. there is also an Wilesco transmission between the engine & generator. the chimney & support have been deleted (i thought they detracted from the water tower) an access door was made for the rear of the boiler firebox. the electrical cord goes through a tunnel in the base.
