Foam Board T-45 Goshawk RC Jet Plane

Actually this model was not planned before. I have an ongoing "secret project", but apparently that project was very hard to make and very time consuming, I need to switch to an alternative project that is quick and simple to build. At first I was going to make a fun-jet, but then again I don't like a non-scale aircraft, so I switched again to F-8 Crusader. But I remembered that I saw some comments requesting T-45 Goshawk. I've done that jet in the past, and it's simple and also beautiful with "eye catching" color scheme. Finally I pick this T-45 Goshawk. I reduce the size to 800mm in a hope that it will have bigger power. I also make available for 900mm wingspan plans.

SUBSCRIBE and Like to support this channel
#t45goshawk #rcplane #buildvideo

You can download the plans on the link below :
800mm A4 Plans : https://paper-replika.com/RCplans/PR_...
800mm A0 Plans : https://paper-replika.com/RCplans/PR_...
800mm Decal A3 : https://paper-replika.com/RCplans/T45...

900mm A4 Plans : https://paper-replika.com/RCplans/PR_...
900mm A0 Plans : https://paper-replika.com/RCplans/PR_...
900mm Decal A3 : https://paper-replika.com/RCplans/T45...

Build instructions :
https://paper-replika.com/index.php/r...

DONATE via Paypal : Juliusperdana@yahoo.co.id

Join this channel to get access to perks:
   / @juliusperdana


Playlist :
00:00 Intro
04:03 Plans Preparation
04:59 Fuselage
09:58 Stabilizers
10:29 Wing
14:52 Air Intake
16:31 Covering
21:40 Canopy & Decals
25:56 Motor & Pushrods
29:01 Landing Gear & Accessories
31:09 Rudder & CG
35:41 Maiden Flight
42:38 Review & Next Project?

Specs :
1. Wingspan 800mm / 31.5 inches
2. Flying weight : 850 grams/ 30 oz
3. Wing loading :68.5 gram/dm2 - 22.5 oz/sq.ft.
4. Wing cube loading : 19.5
5. Wing Area : 12.4 dm2 / 192 sq.in.
6. CG : 11.8 cm from LE

Electronics
Tested with 2826 2200kv brushless motor with 6X4 propeller
2212 motor/ drone race motor
40A ESC
Battery Lipo 3S 2200mah / 1300mah
4 plastic gear 9 gram servos (micro servo) https://amzn.to/2X5GdXH

Materials :
1. 5mm Depron/ Polyfoam
2. 3mm Plywood / PVC foam board
3. 0.5mm Mica Plastic
4. hot glue, UHU glue, CA glue
5. packing tape/ laminating film https://amzn.to/3ttYTMp
