Analog Input scaling in Delta PLC

Scaling analog input signals in a Delta PLC involves mapping the raw analog input values from sensors or other devices into meaningful engineering units. This process is essential for interpreting the data correctly within your control system. Here are the general steps to scale analog input signals in a Delta PLC

00:00 intro
01:10 Analog Input in Delta PLC
04:37 Floating Point value
07:06 Analog Scaling

Define scaling constants or variables to map the raw analog input values to engineering units. You typically need to use linear scaling, represented by the equation.



PID WITH ANALOG I/O
   • Analog Input scaling in Delta PLC

#ScaledValue = (RawValue - RawMin) * (EngMax - EngMin) / (RawMax - RawMin) + EngMin
Where:
#ScaledValue is the scaled/converted value in engineering units.
#RawValue is the raw analog input value.
#RawMin and #RawMax are the minimum and maximum values of the raw input signal.
#EngMin and #EngMax are the minimum and maximum values in engineering units.
