How to install a RocketCPU WPC-89-S in a Bally Williams pinball machine

The RocketCPU is a drop-in replacement board for your original WPC-89 or WPC-S CPU. Fully compatible with your Bally / Williams pinball machine.

This tutorial video will guide you for the RocketCPU WPC-89-S setup, from start to finish.

Exact same schematics as original, with some extra features: integrated No More Reset, CR2032 battery, remote battery holder, shrouded ribbon connectors, high accuracy clock and more.
_______________________________________________________________________

👉 Buy your RocketCPU here :
https://www.pinsound.org/shop/en/102-...
_______________________________________________________________________

🟧 Visit our site for more information: https://www.pinsound.org
🔵 Follow us on Facebook:   / pinsound
📷 Follow us on Instagram:   / pinsoundpinball
_______________________________________________________________________

0:00 Intro
0:07 1) Open the backbox
0:21 2) Disconnect and remove the Original CPU
1:13 3) Remove the Asic U9
1:27 4) Remove Eprom U6
1:35 5) Remove Processor U4
1:54 6) Transfer Asic U9 to RocketCPU
2:13 7) Transfer Processor U4 to RocketCPU
2:29 8) Transfer Eprom U6 to RocketCPU
2:44 9) Insert CR2032 Batteries
2:52 10) Install the RocketCPU in the backbox
3:25 11) Check the Smart Status LED
3:39 Visit our website for more info
