EP 3 Revit MEP Electrical Full Residential Beginner Course - CIRCUITING

🔥DOWNLOAD the free package of models & custom electrical template with families HERE https://www.electricrob.com/offers/42...

If you haven't watched Episode 2 yet (starting electrical design) then watch Here!    • EP 2 Revit MEP Electrical Full Residential...

🔥🔥Or, if you want to see the entire 8 episodes in one massive course, try here!    • Entire House! - REVIT MEP ELECTRICAL Full ...

This EPISODE 3 gets right into electrical circuiting of the devices we installed in the previous episode! Install a 120/240V Split-Phase panel/loadcenter, circuit up receptacles and mechanical equipment, tag devices with circuit numbers, and create a panel schedule. Stay tuned for Episode 4, where we will install lighting fixtures and lighting controls!

If you are ready to master Autodesk Revit, specifically for the MEP Electrical trade, focusing only on the absolutely necessary concepts, then this video series is exactly what you need! I will guide you step by step from a blank project to a complete 3-bedroom residential house electrical design, complete with receptacles, HVAC and plumbing equipment connections, light fixtures, light switches, a panel or residential loadcenter, the service meter, and even out to the utility transformer at the street.

Plus I will give you everything you need, up front, to follow along with me, entirely FREE, which you can download above.

So this package includes - the 3D architectural model - the 3D mechanical model - my custom residential electrical project template to start from with all the settings set up - and every single out-of-the-box electrical family you will need to create your own version of this model, including a bonus of 2 custom generic electrical families that you can use for many other electrical devices!

So if you are finally ready to become proficient in Revit Electrical, then let's get right into it!

Chapter Timestamps:
00:01:37 Add a 120/240V Split-Phase Panel/Loadcenter
00:06:33 Circuiting Receptacles
00:13:48 Create Panel Schedule
00:19:26 Circuit Mechanical Equipment
00:22:24 Circuit Laundry Room
00:27:50 Circuiting the Kitchen
00:35:50 Circuiting the Rest of the House
