A Rotary airlock, also known as a rotary valve or rotary feeder, is a mechanical device used in various industries to control the flow of bulk solids or powders between different parts of a system while maintaining an airtight seal. The primary function of a rotary airlock is to feed material from a hopper or a silo into a conveying system, dust collector, or any other vessel, while preventing air or gas leakage.

The design of a rotary airlock typically consists of a cylindrical housing with a rotating rotor inside. The rotor has vanes or blades that create pockets or compartments as it turns. When the rotor is rotating, these pockets allow the material to enter from one side and then discharge it to the other side while maintaining the separation between the inlet and outlet. The rotation of the rotor is often driven by an electric motor or an air-driven actuator.

Rotary airlocks are commonly used in a wide range of industries, including:

Pneumatic conveying systems: To control the flow of materials in a pneumatic transport system, where materials are moved through pipes using air pressure.

Dust collection systems: To transfer collected dust or particulate matter from the dust collector to a disposal container without allowing air to escape.

Industrial processing: In processes like mixing, blending, and granulation, where controlled feeding of materials is crucial for the proper functioning of the system.

Chemical and pharmaceutical industries: For transferring materials between different processing stages while maintaining a controlled environment.

Food processing: In applications such as conveying flour, sugar, spices, or other food ingredients in a controlled and hygienic manner.

Agriculture: In agricultural applications, such as feeding grains into livestock feeders or transferring seeds and fertilizers.

The appropriate type and size of the rotary airlock depend on various factors like the material properties, flow rate, pressure, and temperature requirements of the specific application. Regular maintenance and proper selection of materials of construction are essential to ensure smooth and reliable operation and to prevent wear and tear.
