The Most Absurd Breville Bambino Teardown
Автор: Tech Dregs
Загружено: 2023-10-28
Просмотров: 42526
A deep dive into the Breville Bambino espresso machine, showing parts, construction, and assembly. This is an inexpensive (cheap?) espresso machine (considered to be the minimum viable machine by many) which may serve as an interesting project platform. This video might be helpful for that or as a repair reference.
Schematic and datasheets: https://github.com/techdregs/Breville...
Flow Meter: ODE AB32-S21PO12C-11R
Pump: Ulka EP5FM
Solenoid: JLT P3T04125LA
Heater: Ferro Techniek FTH II 1500W
Triac: WeEn BTA425Y-800BT
MCU: STM32F070CBT6
=== Timestamps ===
00:00 Introduction
01:42 Cheap Accessories
02:45 Exterior Parts
04:08 Opening the body
06:42 Water Route/Flow Meter
07:52 Pump and OPV
08:45 Solenoid and Drain Line
10:35 Heater Demo
11:30 Thermal Imaging
13:30 PCB Removal
18:41 PCB/Electronics Overview
21:20 Pump Mount and Triac
22:21 Heater Assembly Removal
27:18 Heater Core
32:17 Finding a Lost Screw
32:38 Top Internal View
33:15 Group head Feed Line
34:12 Solenoid Assembly
35:35 Steam OPV Internals
38:10 Solenoid Dissection
42:36 Front Control Assembly/Buttons/PCB
46:50 Reassembly of Top End
51:30 Shower Screen and Group Head
53:15 Overall Thoughts/Comments/Conclusions
