Sliding Table Panel Saw

More info at http://scosarg.com/manufacturers/martin

Experience Perfection with the Martin T70 Panel Saw,
like every MARTIN machine the T70 is built for maximum performance. This German designed and manufactured sliding table panel saw is manufactured to the highest engineering tolerances, using the very highest quality components the T70 ensures long lasting repeat cutting accuracy and operational reliability.

Cutting-Edge Control Technology
At the heart of the T70 is the user friendly 10.4" touch screen control unit positioned at eye level. From here the operator is guided through even the most complex working processes easily, quickly and accurately. All the relevant information is visible at a glance and even on the base model the operator has control of 3 cutting axis for the height, angle and cutting width through the motorised rip fence. If the machine is equipped with the optional 3 axis controller, this is also integrated in the control software. As standard the machine has a massive cutting height of 204mm at 90 degrees when using the 550mm dia blade. The large cutting height is possible thanks to the heavy duty composite frame to ensure max rigidity and cutting precision. Other standard features include Prolock quick blade change. The machine can be configured to suit customers individual production requirements thanks to the number of options that can be specified.

Rip fence
The T70 is equipped with a motorized rip fence as standard that helps you position the cutting width quickly and precisely. The intuitive touch screen controller helps to substantially reduce human errors when it comes to measuring and helps to contribute to the perfect cut. The precision rip fence's wear-free grooved ball-bearing guide system further ensures precise positioning and a high degree of angular precision over the entire cutting width. The rip fence glides over the machine table smoothly, unaffected by dust and chips. The unique MARTIN design makes the lowering of the rip fence below the table level quick and easy. This allows even long workpieces to be sawn. If the rip fence profile is laid on its side for veneer overhang applications, the controller senses this and compensates for the change in cutting width. To manually move the rip fence, simply press the button located on the fence
and set to the desired postion.

Technical Specification:
Motor power 5,5 kW (7.5 HP)
Optional 7,5 / 11 kW (11 / 15 HP)
Cutting height saw blade Ø550 mm max. 204 mm (8")
Saw-blade tilt range 0° to 46°
Saw-blade diameter 250 - 550 mm (10" - 21.6")
Rotational speed 2800 / 4000 / 5000 rpm
Optional Infinitely variable from 2000 to 6000 rpm
Optional scorer d=22mm x Dia=125mm
Main saw blade change ProLock
Blade thickness max.6mm / special tools max. 20 mm (0.79") (at 90 deg.)
Cutting width 850 mm
Optional 1100 / 1350 / 1600 mm
Cross-cut fence length 190 - 3310 mm
Standard Sliding-table length 3,0 m (9' 8")
Optional 1,9 / 3,3 / 3,7 / 4,3 / 5,1m
Controller PowerPC
Control panel T70 Touch screen, color; TFT 10.4" (264 mm)
Control panel in VGA resolution
Cutting angle / height / width controlled
Display resolution 0,1 mm or 0,01°,
repeatable accuracy ± 0,05 mm or ± 0,005°
