Ebay $1.50 Filament LED lightbulb teardown (2W)
Автор: DiodeGoneWild
Загружено: 2017-01-24
Просмотров: 115275
Описание:
Teardown of a filament LED lightbulb from Ebay for $1.50 including shipping. Rated 220V 50Hz, the nominal power is 2W, real power is cca 1.6W, it has a E14 screw base. It is quite bright and looks nice, but there's no fuse in it. There's also no filter capacitor, so it has a lot of 100Hz flicker (not visible to the human eye unless you move it fast). It has a capacitor dropper in it with a 330nF capacitor, 1M discharge resistor and 1k inrush resistor. The 330nF multi layer ceramic capacitor looks quite small for the mains voltage.
