Construction Site | Electrical Equipment & Earth Bonding | MI 3325, MI 3288 | Instructional

In this instructional video we demonstrate how to ensure the electrical safety of electrical equipment on construction sites using the MI 3325 MultiServicerXD, paired with the A 1422 Active 3-Phase Adapter Plus and the A 1722 PRCD Testing Adapter. We also cover how to use the MI 3288 Earth Insulation Tester to accurately test earth bonding.

The MI 3325 MultiServicerXD is a portable tester designed for electrical safety testing of electrical equipment, together with the SW 1201 Metrel Electrical Safety Manager (MESM) software.

The MI 3288 Earth Insulation Tester is a Metrel earth/insulation tester for measuring earth resistance, specific earth resistance, earth potential, step and touch voltages, insulation resistance, and continuity of protective conductors.

—
⏲️ TIMESTAMPS
00:00 – The Importance of Safety & Quality
01:00 – Overview of MI 3325 and A 1422
01:23 – Connecting to the Instruments
01:44 – A 1722 PRCD Adapter Explained
02:00 – How to Save the Results
02:09 – Repeating the Procedure
02:23 – Testing in the Tunnel
02:43 – MI 3288 EI Tester Overview
03:10 – A 1593 Leakage Kelvin Test Crocodile Clips
03:23 – Starting the Measurement Procedure
03:42 – The Importance of Assistance
04:12 – Saving the Final Results
04:25 – Don’t Forget to Subscribe!

—
