Picked up a John Deere X540 off Facebook with a serious complaint: it lost oil pressure while mowing.

This tractor runs a Kawasaki FD731V-HS02 and when oil pressure disappears, you have to prove whether the engine is still worth saving before you throw parts at it

In this video we confirm the no oil pressure condition, then walk through the exact checks I use to determine whether the engine has internal damage

We perform a leak down test on both cylinders and verify they hold pressure (about 98%), then use a borescope to inspect cylinder walls for scoring, We also drain the oil to see what it looks like

With the basics looking good, we pull the engine and go deeper

We remove the FD731 Engine and access the crankcase sump cover and water pump

Remove the water pump/impeller and inspect the sump area

Inspect the oiling system and find the common failure point: a bad oil pump gear

Check for metal/debris with a magnet and inspect oil for aluminum glitter. Aluminum glitter is obviously not magnetic but other metals that are ruined during engine failure are

Replace the oil pump gear and reassemble correctly

Seal the crankcase cover using Permatex Ultra Gray (no traditional gasket sold)

Replace the water pump gasket and water pump o-ring

Reseal the oil pump o-rings where the sump mates to the crankcase

Inspect the oil pressure relief valve spring and ball

Reinstall the engine and verify it’s back in service

If you own a John Deere X540 (or anything running a Kawasaki FD series engine) and you want a real-world save-or-scrap oil pressure diagnosis, this is the full process from start to finish

The links contained here are affiliate links for which we may be compensated if you make a purchase

OTC Leakdown Tester https://amzn.to/47PSXjp

Parts Used:

M76098 Oil Pump Gear https://amzn.to/3YSSlYe
MIU10868 Water Pump Gasket https://amzn.to/3Nw1G5R
MIU10839 Water Pump O-Ring https://ebay.us/DolrL0
AM107423 Oil Filter https://ebay.us/fQug5R
Engine Oil https://ebay.us/ELCCZd

If You Need Additional Parts:

M138445 Oil Pressure Switch https://amzn.to/4pUB2kB
MIU11329 Oil Seal Between Water Pump & Crankcase https://ebay.us/DolrL0
MIU11328 Mechanical Seal (Porcelain Two Piece Just Behind Impeller) https://ebay.us/6XWPsZ
MIU10830 Water Pump Impeller https://ebay.us/dmdjd8
MIU10832 PTO Oil Seal https://ebay.us/koE9Tb
