(2009-2016) Citroen DS3 Fuse Box Diagrams and Fuse Panel Locations✅
Автор: FuBox
Загружено: 2025-05-30
Просмотров: 1133
Fuse panel locations and fuse box diagrams for: Citroën DS3 2009, 2010, 2011, 2012, 2013, 2014, 2015, 2016.
Source: https://fubox.net/citroen/ds3-2009-2016/
Fuse Box Diagrams and Fuse Panel Location for models:
2009 Citroën DS3
2010 Citroën DS3
2011 Citroën DS3
2012 Citroën DS3
2013 Citroën DS3
2014 Citroën DS3
2015 Citroën DS3
2016 Citroën DS3
Citroen DS3 Fuse Box Locations (2009–2016):
1. Dashboard Fuse Box (Passenger Compartment)
Left-hand drive (LHD): Located in the lower dashboard (left side).
📌 Access: Unclip the cover from the side and remove it fully.
Right-hand drive (RHD): Located inside the glove box.
📌 Access: Open the glove box and unclip the cover on the side.
2. Engine Compartment Fuse Box
📍 Located near the battery on the left-hand side of the engine bay.
⚠️ Access: Unclip and lift the cover to reach the fuses.
