MECHMAN PSC+ (Power Sequence Controller) Review

Lazada Link
Black:
https://www.lazada.com.ph/products/i4...
Silver:
https://www.lazada.com.ph/products/i4...

Shopee Link
Black:
https://shopee.ph/product/387459005/2...
Silver:
https://shopee.ph/product/387459005/2...

8+2 (Universal Socket)
8 at the back (30A relay each + EMI filters)
2 at the front
1 USB for light/charging
63A MCB Main Switch


Power input conditions (single-phase 3-wire): AC220-240V (optional AC90-240V) 50-60HZ two-phase (three-wire: zero, fire, ground).

8-way universal socket relay controlled and 2-way universal socket direct output.

Controlled output of relay, maximum single circuit power/total power (reactive power): 2000W/6000W, maximum reactive power.

Sequential opening and reverse closing.

Accurate voltage display.

Interval time/timing time of each switch: 1.5 seconds.

Output relay contact current: 30A 277 VAC.

Circuit board specification: double-sided fiberboard, secondary thickening and thickening treatment for main power supply wiring.

Power supply specification: built-in transformer voltage AC220-240V.

Main cable specification: 3 * 4 square cable, with a total length of 1 meter (equipped with power input plug).

Function display voltage display type: Blue Nixie tube display voltmeter

480MM long * 165MM wide * 48MM high (non-standard 1U)

Single unit packaging size: length 510MM * width 260MM * height 100MM

Total weight (including packaging): 3KG
