Repair of the NAD D-3020 Hybrid Digital Amplifier which does not power on. The power LED illuminates orange in standby. When powering the unit up, the front flashes 5 times followed by a red standby light, then back to orange.

Repair of the power supply and the Class D Hypex UcD102 amplifier board with blown output transistors.

Support the Channel with Patreon:   / sdgelectronics
----------------------------------------------------------------------------------------------------------------------
0:00 Introduction
3:48 Amplifier Architecture
8:14 Initial Troubleshooting
12:53 SMPSU Power Supply Troubleshooting
33:08 Class D Amplifier Board Repair
46:51 Reassembly and Testing
----------------------------------------------------------------------------------------------------------------------
