How To Measure Crank/Chainrings Size BCD
Автор: RJ The Bike Guy
Загружено: 2015-12-01
Просмотров: 167068
I show how to measure a chainring or crank to be able to replace a chain ring. The main things you need to know are the number of teeth and the BCD (Bolt Center Diameter). Well, and the number of holes. I show what to measure and how to calculate or look up the BCD.
As referenced in the video, this is Sheldon Brown's BCD crib sheet:
http://www.sheldonbrown.com/cribsheet...
The multipliers I used to calculate BCD by measuring the distance between adjacent bolt holes are:
3 bolt x 1.155
4 bolt x 1.414
5 bolt x 1.699
6 bolt x 2.000
Some of the most common BCDs:
4 hole: 64mm, 80mm, 104mm, 120mm
5 hole: 74mm, 110mm, 130mm, 135mm
