Power Transformers: Basic Design and Function
Автор: Uncle Doug
Загружено: 2014-01-31
Просмотров: 156432
In this video, I discuss the design and function of Power Transformers (PT), primarily those utilized in amplifiers. Topics such as winding ratio, output voltage, current limitations, and mounting characteristics are explained. Then, using a Fender Deluxe Reverb as an example, we analyze the voltage and current requirements of an amplifier. Using those parameters, we select an appropriate replacement PT for the amp. NOTE: These same parameters will also allow you to select the appropriate PT for a home-built amplifier project.
As if this weren't enough, star camera-hound Rusty appears several times, especially in some dramatic "Outtakes" at the end of the video.....so stay tuned until the end so you don't miss his Emmy-worthy performance.
If you enjoy videos featuring classic vintage amplifiers, jukeboxes, hand-built electronic projects, occasionally sarcastic humor, and (hopefully) clear, concise technical presentations, then please subscribe to my channel. You will gain immediate access to about 90 more videos, and (if you activate the service) you will be notified each time a new video is posted.
Thanks for watching !!!!
