AR Mini FPV Wing Review - 600mm / 24" Moulded Black EPP Wing

Howdy, this is the full review of the AR Mini wing I bought here http://bit.ly/2xlL7j2 This little 600mm or 24" wing is mental and is specifically designed for FPV, unlike other models that have been "bent to be usable" for FPV. Full details below, press SHOW MORE to see them, Matt

IMPORTANT
================
So that we're ALL on the same page. I feel it's important to stress that the Sonicmodell Mini AR Wing model was bought out of my OWN money, for my own abuses and was NOT a "Freebie for Review".

Sonicmodell Mini AR Wing
==
You can view/purchase this model here http://bit.ly/2xlL7j2

The parts I used:

D4R-II Receiver: http://bit.ly/2KsVVkb
TX526 vTx: http://bit.ly/2HBOKVm
Clover Antennas: http://bit.ly/2Fmey5z
Caddx FPV Camera: http://bit.ly/2zRyvBQ

Lost Model Alarms
==
In the video I mention the use of a lost model alarm, they're cheap and can be found here http://bit.ly/2IFKQKI

Description
==

This is the description from the BG site here http://bit.ly/2xlL7j2

The Mini AR.Wing is a 600mm pure breed racing wing. Even being way smaller than her big sister, the original full sized AR Wing, the mini still keeps all the awesome features that fans loved about the AR. Wing.

The high strength EPP material with built-in carbon fiber tube and strips makes it rigid and resistant to crashes and abuses. Her compact size and pre-installed power system will make it easy to carry around and get you in the air in no time.

The high quality analog 8g servos will ensure youʼll have an agile and accurate performance.Featuring a huge equipment bay for its size,you can load her with a 3-4S 800-1300mAh battery to get more than 10 minutes flying time.

All in all, a tiny beast that will assure you hours and hours of thrilling action!

Features:
===========
Black EPP molded wing and fuselage, durable, light and flexible.
Built in carbon fiber tube and spar, rigid and super crash resistance.
Compact size, perfect for casual FPV action.
Bonus camera mount, compatible with all FPV and AIO cameras in the market.
Extra plastic cover for protecting the main wing leading edge from damage.
Carefully designed skids for hand grip launch and landing.
Stable flying performance, 10-70km/h flying speed.
Huge equipment bay for more FPV gear and bigger battery.
Plywood for fuselage with pre-cut FC mount.
Convenient and clear “CG” mark under the main wing.
"NACA" Air intake and outlet for FPV gear cooling.
With two color decals, red and black.

You can view/purchase this model here http://bit.ly/2xlL7j2

Specifications:
==========
Brand Name: Sonicmodell
Item Name: Mini AR Wing
Material: EPP
Airplane Color: Black
Decal Color: White, Red
Wingspan: 600mm (23.6'')
Length: 212mm (8.35'')
Wing Area: 8.84dm²
Wing Load: 39.5g/dm²
Flying Speed: 10-70+km/h
Motor: 1806 2400KV
ESC: 30A with 5V/2A BEC (XT60 Plug)
Servo: Analog 8g *2
Propeller: HQ5045
CG: 64mm from the main wing front lead
Airplane Weight: 143g
Package Weight: About 600g
Package Size: 360x190x120mm
Battery Compartment Size: 90x110x25mm

Recommended Parts for Mini AR.Wing (Not Included):
================
Battery: 3S 11.1V 1300mAh or 4S 1100mAh LiPo,
Charger: SkyRC Balance Charger
Control System: 2.4G 4CH
Compatible Camera: Foxeer HS1177/1190
Flight Controller: F3 - F4 Series
FPV VTX: 5.8G

Sonicmodell Mini AR Wing
======================
You can view/purchase this model here http://bit.ly/2xlL7j2
