Exhaust fan winding|410 watts almonard exhaust fan winding|Fan repair|Fan winding connection diagram

#ExhaustFanWinding
#motorwinding
#fanRepairing
#almonardexhaustfanwinding
#24slotfanmotorwinding
#410wattsfanmotorwinding
410 watts Exhaust fan motor winding
Almonard exhaust fan winding and winding diagram and connection diagram full video
Fan winding connection diagram
Hi power electric works
How to rewinding exhaust fan motor
24 slot 1440 rpm fan motor winding and connection
Brand- Almonard exhaust fan
Watts -410
Running coil-- 2 Double coil set
1-5=165 turns-former 21 cm
1-7=165 turns- former 28cm
2 single coil set 1-5=165 turns two sets
Starting coil---2 double coil set
1-5=185 turns
1-7=185 turns
2 set single coils 1-5=185 turns
Running SWG -24 Weight -570 gram
Starting SWG -27 weight -350 gram
Core length 3.5 cm
Core dia - 8 cm
Slot 24
Amp 1.8
Capacitor 8 mfd
Thanks for watching please subscribe and support my channel for more videos 🙏🙏
