Subscriber's Request - Installing 4 in 1 Multiprotocol Module Deviation Walkera Devo 10
Автор: Johnny Tu
Загружено: 2016-12-03
Просмотров: 7970
Please like and subscribe to jtgravityRC for more videos! Thanks! Cheers!
4-In-1-RF-Module-For-Walkera-D7E-D10-
https://goo.gl/ihKSRe
I understand from a subscriber that there is lack of instructions as to where to solder the 3 wires on the Devo 10. From my experience modding the 3 in 1 module, I found that this 4 in 1 module is basically the 3 in 1 module incorporated into the onboard type module which does away with all the other necessary wiring e.g. power and others leaving on 3 wires for the C2500, NRF2401 and A7105 to connect to Devo 10. I figured out that they should to to the same points on the Devo 10 as for the 3 in 1 module. I think I am right on that. Enjoy! :)
