How to Make a Digital Fan Regulator | Diy Smart Fan Regulator | Humming Free

How to Make a Digital Fan Regulator | Diy Smart Fan Regulator | Humming Free

In this video, you will learn how to make smart fan regulator at your home

Make your home smart

watch the full video to know more about it.
Anyone can make this project.

So Friend, how do you like this video? Be sure to let me know in the comments.



💕 Follow me on 💕
👇
🔴 Instagram :-   / theelectronicsadda
🔵 Facebook :-   / theelectronicsadda


More Updates Please Subscribe Our YouTube Channel click
Link:-    / theelectronicsadda

Watch More Videos on My Channel
Link:-    / theelectronicsadda



Code:- https://drive.google.com/file/d/18Va6...

Mobile App :- https://drive.google.com/file/d/1w8AK...

Circuit Diagram :- https://drive.google.com/file/d/1XgSP...

---------------------------------------------------------------------------------------------------------------

** Components List **
----------------------------------------------------------------------------------------------------------------

1 * ATmega8A PU Microcontroller

1 * 28 pin IC Base

1 * 16mhz Crystal

2 * 22pf

1 * 7 Segment Display ( Common Cathode )

1 * HC-05

1 * TSOP1738

4 * 330R Resistor

3 * 1K Resistor

2 * 2.2 Ohm 1/2w Resistor

1 * 10K Resistor

2 * 220K Resistor

1 * 220 Ohm - 2Watt Resistor

1 * 0.1uf-400V Capacitor

1 * 10D511K MOV

3 * BC547

3 * 1N4007 Diode

3 * 5V Relay

1 * 4.7uf-400V Capacitor

1 * 2.2uf-400V Capacitor

1 * 100uf-16V Capacitor

1 * Mobile Charger Circuit

2 * Blank Plate

1 * Male Header Pin

1 * Female Header Pin

1 * Zero PCB


------------------------------------------------------------------------------------------------------------------------
