Magic Tee (Basics, Working, Internal structure, S Matrix & Applications) Explained in Microwave

Magic Tee / EH Plane Tee in Microwave is explained with the following outlines:

0. Magic Tee
1. Magic Tee Basics
2. Magic Tee Internal Structure
3. Magic Tee Working
4. Magic Tee Applications
5. Magic Tee Scattering Matrix

Engineering Funda channel is all about Engineering and Technology. Here this video is a part of Microwave Engineering.
