"What Doesn't Hertz, Makes Us Stronger" - Part 10 Griffin GB-707A, aka Denon 700 Reel to Reel

Welcome back to the Griffin 700 Restoration Project—Episode 10 (two more to go)! This time, we dive deep into the world of oscillators, voltages, and finely tuned adjustments as we tackle the next big step in the restoration process.

🔍 In this episode, we cover:

The bias oscillator and its relationship to the erase oscillator.
Using the oscilloscope to analyze amplitude, frequency, and erase voltages.
Restoring balance across the channels, ensuring all signals are right where they need to be.
Why bias voltages are so critical for recording quality.
We’ll guide you through testing, calibration, and the ultimate victory—bringing this vintage tape deck to peak performance! And guess what? The fire department stayed out of this one. No smoke, just smooth signals and happy circuits.

✨ Key Takeaways:

Learn to measure peak-to-peak values and adjust bias for optimal recording.
Discover why calibration with wide-open pots ensures better results.
Laugh along as we navigate left-is-right chaos and vintage tech quirks.
🛠️ Fun Fact: Even with decades-old gear, the right tools (and a little patience) can make all the difference.

If you’re an audio restoration enthusiast or just love watching vintage electronics come back to life, this episode is for you.

👍 Like, comment, and subscribe to stay tuned for future episodes as we inch closer to completing this iconic restoration. And to our amazing Patreon supporters, thank you for helping keep this project alive!
