How to Wire an Extractor Fan or a Second Light From a Ceiling Rose and Pendant

How to add a 3 core and CPC cable (supply) from a light to feed a bathroom extractor fan or take the supply and switch wire to another light. In this video we look at the layout of a ceiling rose and its connections - loop, neutral and switching line and how best to lay them out the new 3 core cable conductors. At college we often have only 2 twin and CPC (twin and earth) cables at the lighting points during training but often in the real world this would be 3 cables. With 3 cables already installed within a ceiling rose it can look full but you can still add cables to it. The connections in the ceiling rose are for the 3 plate method of wiring a lighting point explained in this video.

🔔 Subscribe for more free electrical training videos https://youtube.com/c/GSHElectrical?s...

== 🕐 Time Stamps - Cut to the action 🕕 ==
00:00 - Wiring to an extractor fan
00:23 - 2 lights coming on at the same time
01:08 - 3 core and CPC cable
01:58 - Black or grey as neutral?
03:04 - Connecting the CPCs
03:36 - Screw on the floor is a screw I will see no more
03:52 - Connecting our grey neutral
05:00 Connecting our line
05:36 - Connecting our black switch line
06:25 - Finished connections

Videos are training aids for City and Guilds (C and G) and EAL courses Level 1, 2, 3 plus AM2, AM2S and AM2E.
