Harbor Freight Parts Washer Filtration System - The Finished Project

See bottom of the description for links to the parts I used.

Improved Harbor Freight Parts Washer Filtration System - The Finished Project

[Video where I discuss my plans for the filtration system.
   • Improved Harbor Freight Parts Washer Filtr...  ]

I finally got around to implementing my filtration design on my 25-year-old Harbor Freight parts washer.

In this video, I explain what I did to install the filtration system as well as show my mistakes, so you don't have to make the same mistakes.

The main improvements to designs of other users are:

1.) Installing the filter above the fluid level, to prevent the fluid from siphoning from the tank when the filter is removed. Other users have installed the filter below the fluid level and had to install an additional shut-off valve to prevent siphoning.

2.) Using bulkhead fittings rather than route hoses through holes in the side of the tank. Hoses routed through holes in the tank will allow splashed fluid to leak and run down the outside of the tank. Bulkhead fittings prevent such leaks.

3.) Adding diagonal bracing to the legs after moving the shelf to the bottom.

Parts used:
(As an Amazon Associate I earn from qualifying purchases, with no cost to you.)
(1) Derale 25044 Remote Filter Mount Kit https://amzn.to/3LQjfbl
(1) Fram PH8A oil filter https://amzn.to/35bs3If
(5) 90 degree fittings (1/4 in. NPT x 3/8 in. hose barb) https://amzn.to/3H17Z8t
(1) 45 degree fitting (1/4 in. NPT x 3/8 in. hose barb) https://amzn.to/3gYDBkz
(1) 90 degree fitting (3/8 in. hose barb x 3/8 in. hose barb) https://amzn.to/3LN0tlq
(2) 5/8 in. oil pan drain plug gaskets, OD=1-5/16 in. (drilled to 3/4 in. hole)
(2) 1/4 in. NPT bulkhead fittings https://amzn.to/3sQqPKB
(8) 3/8 in. spring hose clamps
Teflon plumber's tape https://amzn.to/3p2Q1fz
Pipe joint compound https://amzn.to/3I4AW4U
17 in. of 3/8 in. fuel hose https://amzn.to/35ekT60 (Quantity = 2 for 2 feet)
(2) 5/16 in.-18 x 3/4 in. bolts
(2) 5/16 in.-18 nylon locking nuts
(1) Fumoto F108N drain valve https://amzn.to/36wORCZ
(1) Fumoto NC-10 plastic nipple cap https://amzn.to/3s6q6Wy
(1) 6 ft. length of 1-in. flat stock https://amzn.to/35bhV2a
(1) can of royal blue spray paint https://amzn.to/33znZAT
(2) 5-gallon cans of PSC-1000 parts washer solvent https://www.tractorsupply.com/tsc/pro...
