Join James and Trevor as they explore the Advanced Serial Filtering capabilities in PicoScope 7.2. Sifting through hundreds or thousands of data packets to find a specific error or value can be a challenge, but the new filtering tools make it easy to isolate exactly what you need.
In this demo, Trevor uses an I2C signal to show how to:
• Filter by Operation: See how to narrow down results—for example, by filtering only for "Write" commands using the "equal to" operator—to remove unwanted read packets from the view.
• Filter by Data Content: Learn how to use index filters to view specific columns of data (e.g., columns 0 to 1) within a packet, allowing you to focus on specific bytes of interest.
• Visualise Results: Discover how the software creates a second line on the graph, displaying just the filtered data below the complete packet for clear, comparative analysis.
PicoScope 7 is available now as a free update for Windows, Mac OS, and Linux users. Download it from our website to take advantage of these new features.
