Ultimate Rear Diff Bushings DIY - F80/F82
Автор: Tuned Auto
Загружено: 2022-10-20
Просмотров: 34406
My notes:
-There are some oddball bolt sizes so make sure you have:
T30, T60, E18, 6mm Allen, 16mm, 21mm
-Get Etorx bits in ½” because the subframe bolts are probably seized
BMW tells you to repair the following bolts:
All 4 subframe bolts ( I highly recommend )
All 4 bolts on the front subframe mount ( I highly recommend )
Rear diff mount bolt
All bolts on both V braces
Torque Specs:
-4 bolts on front diff mount - 120nm / 80 ft lbs
-Rear diff bolt - 210nm / 154 ft lbs.
-Vibration damper on rear bolt - 19nm / 14 ft lbs
-Rear diff bracket - 120nm / 88 ft lbs
-4 subframe bolts - 108nm / 80 ft lbs
-6 guibo bolts - 55nm / 40 ft lbs (+ 90 degree)
Parts:
-4x BMW Repair bolts: 07147426660
-4x BMW Repair bolt washer: 31336776760
-4x Replacement subframe bolts: 33302284642
-Guibo bolts: 26117527475
-Guibo but: 26127536563
F80 DIY Writeup: https://f80.bimmerpost.com/forums/sho...
