The RADIAL PLATE is one of the components of the TF coils. This D-shaped stainless steel plate measures 13.4 m x 8.7 m x 0.12 m. The radial plate has on each side spiral round-shaped grooves which are closed by cover plates. Their purpose is to contain the super conductor. In each TF coil there are 7 Radial Plates.
They are made from 316LN stainless steel and they will form the 'backbone' of the 18 field magnets needed to keep the plasma confined within the ITER vacuum chamber.
The properties of the materials used, the quality of the welding, the size of the components, the dimensional tolerances and the sustained pace of the manufacturing operations represent a real challenge from the technological and managerial point of view.
Technologies employed:
NG Tig Welding of HIP segments by ROBOT
Machining on 10 m wide Portal Machine
Temperature controlled room
