USB-C is awesome. I showed that during several previous videos. But I was missing out on 1 feature that USB-C also offers. PPS! Or Programmable Power Supply. By using that you can basically turn your USB-C power source into a variable power supply with adjustable voltage, current limit and much much more. So how easy is that to use and how well does it work? Let's find out!

Websites that were shown during the video:
https://hackaday.io/project/198384-pi...
https://hackaday.io/project/201953-ro...
https://www.mouser.de/ProductDetail/D...
https://github.com/CentyLab/AP33772S-...
https://frame.work/de/en/products/16-...
https://usb.org/document-library/usb-...

Thanks to JLCPCB for sponsoring this video.
Visit https://jlcpcb.com to get professional PCBs for low prices.

0:00 USB-C PPS??
1:33 Intro
2:36 What can PD, PPS do?
3:14 What IC can do that?
4:38 PPS Breakout Board!
5:22 PD Profiles Detect
6:19 Setting a PD Voltage
7:10 Setting a PPS Voltage
8:24 Current/Voltage Monitor
8:50 Max Voltage Resolution
9:11 Charging a LiPo with PPS
10:01 Breakout Board Results
10:12 AVS Feature?
11:10 Final Verdict
