Colpitts Oscillator and a DIY Quartz Crystal Monitor
Автор: Electric Sheep Labs
Загружено: 2016-12-26
Просмотров: 2859
Описание:
The first of many home builds/experiments to come! I solder up a crystal-based Colpitts oscillator. I also cut open the crystal casing to reveal the quartz crystal resonator. Finally, I use the bare crystal as a QCM (quartz crystal monitor/microbalance), and implicate it in use with vacuum deposition systems.
QCM:
https://en.wikipedia.org/wiki/Quartz_...
colpitts circuit:
www.rakon.com/component/docman/doc_download/234-single-transistor-crystal-oscillator-circuits?Itemid=
sharpie line thickness:
• How thick is a sharpie mark?
