Connecting OpenShift Pods to an External MySQL Database: Troubleshooting Tips

Connecting an OpenShift pod to an external MySQL database can often present challenges, ranging from network configurations to firewall issues. In the following sections, we will discuss a common scenario illustrated by a user attempting to connect their OpenShift pod to a MySQL server running on a separate VM and how to troubleshoot the connection effectively.

The Problem at Hand

A user is trying to connect a generic OpenShift pod to a MySQL server located outside the OpenShift cluster. Upon creating the deployment, the user encounters connectivity issues when trying to run a MySQL command inside the pod. The command results in a connection error:

[[See Video to Reveal this Text or Code Snippet]]

Even attempts to ping the MySQL server from within the pod were unsuccessful, raising further questions about the underlying cause of the connectivity challenge.

Investigating the Configuration

The user’s deployment configuration involves:

Service definition for MySQL, specifying the target port as 3306.

Endpoints for the MySQL service that points to the external IP of the host running the MySQL server.

A DeploymentConfig with environment variables containing MySQL connection details like the host, user, password, and database name.

Here’s a simplified overview of the deployment configuration the user was working with:

[[See Video to Reveal this Text or Code Snippet]]

Root Cause Analysis

After reviewing the configuration and testing various connectivity methods, the issue was likely due to a firewall blocking the connection to the MySQL server. While the pod could access the internet, it could not communicate with the MySQL server’s internal network due to restrictions.

Suggestions for Troubleshooting

If you find yourself faced with a similar connectivity problem, here are some troubleshooting points to consider:

Check Firewall Settings:

Ensure that the firewall on the MySQL server's host is configured to allow incoming connections on port 3306.

If you lack access to firewall settings, coordinate with your network administrator to verify connectivity.

Service and Endpoint Verification:

Ensure the Service and Endpoints are correctly pointing to the intended IP and port. You can use the following command:

[[See Video to Reveal this Text or Code Snippet]]

Verify that the ip in the Endpoints configuration matches the MySQL server’s actual IP address.

Pod Network Configuration:

If possible, check if any network policies might be restricting traffic from your OpenShift pod to the external SQL server.

Connectivity Tests:

Use tools like telnet or nc (netcat) from within the pod to test connectivity to the MySQL server's port:

[[See Video to Reveal this Text or Code Snippet]]

Deploying MySQL in OpenShift:

As a temporary workaround, deploy a MySQL instance within OpenShift to confirm that your OpenShift pod can connect successfully to a database in the same cluster.

Conclusion

In conclusion, successfully connecting an OpenShift pod to an external MySQL database can be intricate due to various network and security configurations. By systematically checking firewall settings, validating service endpoints, and utilizing network troubleshooting tools, you can identify the root cause of connectivity issues.

If you continue to run into challenges, collaboration with your network team may provide additional insights on resolving any underlying firewall conflicts. Happy coding!
