Lumencraft Flashlights User Interface Instructions (For Maglite LED Conversion Bulbs)

Installation Video:    • LED conversion Kits for Maglite, Installat...
🔥 Lumencraft Shop: https://lumencraft.com/
🌎 Lumencraft products on Amazon: https://www.amazon.com/shop/mattsmith
☑️ Comprehensive List of Flashlight Recommendations: https://bit.ly/LightsList

0:00 Basic Operation
0:48 Changing Mode GROUPS
3:39 Setting the Turbo Timer

DrJones Guppy2drv (2024 update). This firmware allows the ultimate in user customizability, with 22 built-in mode groups, that the user can select via a series of button presses and the option of user programmable turbo timer that will automatically step the power down to 50% after the set time is hit (see below for instructions).
ML on the chart means Moon Light which is is less that one percent power.

User Selectable Groups:
1.2% - 25% - 100% Memory
2.100% - 25% - 2% | No Memory
3.2% - 25% - 100% - Strobe - Beacon Memory
4.2% - 25% - 100% - Strobe - Beacon No Memory
5.15% - 100% Memory
6.100% - 15% No Memory
7.100% Only
8.100% - Strobe No Memory
9.Strobe - 100% No Memory
10.ML - 5% - 33% - 100% Memory
11.100% - 33% - 5% - ML No Memory
12.ML - 5% - 33% - 100% - Strobe - Beacon Memory
13.ML - 5% - 33% - 100% - Strobe - Beacon No Memory
14.ML - 100% No Memory
15.100% - ML No Memory
16.ML - 100% Memory
17.ML - 5% - 15% - 50% - 100% Memory
18.ML - 5% - 15% - 50% - 100% No Memory
19.100% - 50% - 15% - 5% - ML Memory
20.100% - 50% - 15% - 5% - ML No Memory
21.2% - 15% - 50% - 100% Memory
22.2% - 15% - 50% - 100% No Memory


Guppydrv Instructions

To switch mode groups: rapidly tap the switch 8 times, the light will then enter the programming mode and begin to flash. With the light in programming mode, tap the switch the same number of times as your desired mode group. The light will blink and your mode group will be memorized.

Example: To select mode group 3, tap the switch 8 times quickly to enter programming mode. As soon as the light enters programming mode and beings flashing, tap the switch three times. The light will blink to recognize the mode group change.

To set the turbo timer: rapidly tap the switch 8 times, the light will then enter the programming mode and begin to flash. With the light in programming mode, tap the switch 30 times to enter the turbo timer set mode. The light will then switch to 100% power. When the light is at the desired temperature for the turbo step down, turn the light off. The turbo timer will then be set. The turbo timer steps the light down to 50% regardless of the mode group set.

To disable the turbo timer simply go into program and cut it off in less than 3 seconds
