Sabvoton SVMC 72150 with Wiring harness, Cycle Analyst - complete wiring and setup guide
Автор: QULBIX Performance Electric Bikes
Загружено: 2025-06-26
Просмотров: 937
This video will show you how to connect Qulbix wiring harness to Sabvoton SVMC 72150 sine wave controller (or any other SVMC model). This harness includes signal wires, power cables, phase wires, charge wires, extra connectors and other parts.
A 150 A rated fuse and 0,5mOhm shunt is integrated on P- wire.
This kit will fit perfectly to all Qulbix frame kits like Q76, Q80, Q155 and also Q140MD. The controller is a great match for BLDC motors from QS; 205 V3 and 273.
To round up the setup a Cycle Analyst connection is shown, with twist throttle and variable left-thumb operated regen brake. Also 3-position switch and digital power selector switch is included in the video.
PC programming and hall angle test is also covered.
All items are available in the Qulbix Shop:
https://qulbix.com/qulbix-store/
