DIY Jurassic Park Pinball (with Storm System!).
Автор: Barjo
Загружено: 2024-01-28
Просмотров: 8981
Quick overview of my Arduino based DIY Jurassic Park Pinball. It's made of wood and PLA/PETG (custom 3D print).
Electronic list:
Arduino Mega (for all the sensors and LEDs)
Arduino Nano (for flippers only)
Power socket with On/Off switch
IR sensor
Limit switch
Mosfet Module (to operate solenoids - more voltage)
Arcade button
Large arcade LED button
14 segments display (4 digit)
LEDS (color you want), strip or not
Solenoid 24 VDC / 50N (for flippers)
Solenoid 12 VDC / 35N (T-rex)
Solenoid 24 VDC / 0.75A
12V Fan
220 Ohm resistance (LEDS)
10 KOhm resistance (Buttons)
24V / 12V alimentation
wires
DC connector
Other materials:
Wood
Aluminium stick (like 6-8mm) (for flippers and plunger)
Elastics / springs
Wide range of screws
3D printer with PLA/PETG
Iron Balls 18mm or less
Welding Unit
PCB
Optional:
Cutting machine like Cricut Explore with Vinyle
