How to make a Motion Activated Smart Switch w/ Temperature & Humidity - Tasmota

Create a DIY motion activated smart switch with temperature and humidity sensors. Learn how to create custom automations with Tasmota rules. My previous video of the unboxing and flashing Tasmota Firmware with the Sonoff Basic Template:    • How to Flash the KULED Smart Switch and se...

Smart Switch Models:

VegaHome (Larger LED window on the button)
2 pack - https://amzn.to/2qyMXJA

KULED SmartSwitch:
(2 Pack) - https://amzn.to/2JqvWd6
(4 Pack) - https://amzn.to/2Odbc9v

Gosund Switch with a power logo
(1 pack) - https://amzn.to/2RsRDMs

Parts List:
DHT22 Temp/Humidity Module - https://amzn.to/2JqP2Ql or https://amzn.to/2JtWSZB

PIR Motion AM312 Sensor - https://amzn.to/2DhrkpA or https://amzn.to/2F7P9lE

Male Header Pins - https://amzn.to/2JtX1fB

Female Jumper Wires - https://amzn.to/2DcCiMX

USB FTDI Adapter(for Flashing, set jumper to 3v3 - NOT 5 volts) - https://amzn.to/2Rpu9rx

Products I use and recommend - https://www.amazon.com/shop/digiblurdiy

Come chat with us!
-=-=-=-=-=-=-=-=-=
Discord -   / discord
Patreon -   / digiblurdiy

Sample HomeAssistant Config:

binary_sensor:
platform: mqtt
name: "KLD Motion"
state_topic: "KLDSwitch/PIR/state"
availability_topic: "tele/KLD-Secondary/LWT"
qos: 1
payload_on: "1"
payload_off: "0"
payload_available: "Online"
payload_not_available: "Offline"
retain: false
device_class: motion

sensor:
platform: mqtt
name: "KLD Temp"
state_topic: "tele/KLD-Secondary/SENSOR"
value_template: "{{value_json['AM2301'].Temperature }}"
qos: 1
unit_of_measurement: "°F"
availability_topic: "tele/KLD-Secondary/LWT"
payload_available: "Online"
payload_not_available: "Offline"

platform: mqtt
name: "KLD Humidity"
state_topic: "tele/KLD-Secondary/SENSOR"
value_template: "{{value_json['AM2301'].Humidity }}"
qos: 1
unit_of_measurement: "%"
device_class: humidity
availability_topic: "tele/KLD-Secondary/LWT"
payload_available: "Online"
payload_not_available: "Offline" Please note, the product links above could be affiliate links, using them could earn digiblurDIY a small commission of purchases potentially helping with future video projects. Thank you! As an Amazon Associate I earn from qualifying purchases. Please note, the product links above could be affiliate links, using them could earn digiblurDIY a small commission of most purchases and helps with future video projects. Thank you! As an Amazon Associate I earn from qualifying purchases.
