Halfbridge Tesla coil setup overview
Автор: Elliot Hunt
Загружено: 2020-01-09
Просмотров: 3030
Описание:
Overview on what is going on inside the Dual resonant tesla coil and the parts.
Transistor halfbridge module is rated 1200V 200A
Driver is pretty generic for a DRSSTC mostly derived from Steve Wards work. The PCB layouts i used for etching was by Chester and i changed some component values to suit my setup and parts i had available.
Generally the setup needs tidying but it works. I will be making some modifications so will make it neater after that.
