PCB using Dry Film Photo Resist Technique Double Sided Circuit Board HOWTO
Автор: su pyrow
Загружено: 2017-03-23
Просмотров: 9260
Описание:
Be sure to see my website https://www.supyrow.com for files and extras.
How to make Double Sided Circuit Boards using Photoresist Dry Film and Toner Transfer TEK
In this video I show the basics of how to use Photoresist Dry Film Photo Etch Resist and the Toner Transfer Method of making Printed Circuit boards.
Iron= Black and Decker F210 TYPE 1 / 1200W
Paper= Staples #633215 Color Laser Paper | Gloss Finish | Heavyweight
Developer= Sodium Carbonate
Dry Film= Riston FX515
Etchant= Copper(II) chloride
Software= KiCad-Bleeding-Edge March 24, 2017
Thanks for Watching!
